110DIGITNX2.DOC Page 2 Latest update: 23 Jan -03
Technical specifications
Dimensions:
NX2 MULTI Control instrument: 113 x 113 x 23+28 mm
(4,4 x 4,4 x 0,9 + 1,1 inch).
Server: 110 x 165 x 30 mm (4,3 x 6,5 x 1,2 inch)
Instrument cable:
8 m (26 ft).
Power supply:
12V DC (10-16V). The instruments are polarity protected.
Power
consumption at 12 V:
MULTI Control instrument: 9 mA at 12 V=0,11W
with maximum lighting: 40 mA at 12 V=0,48W
Server: 27 mA at 12 V = 0,3W
Temperature range:
Storage: -30° to +80°C (-22° to +176°F)
Operation: -10° to +70°C (14° to 158°F)
Weight:
MULTI Control instrument: 260 gram (9,17 oz).
Server: 240 gram (8,5 oz)
Enclosure:
MULTI Control instrument: Water proof acc. to IP 68/IP66
Server: Splash proof
CE Approval:
The products conform to the EMC requirements for
immunity and emission according to EN 50 081-1.
