205SP-listNX2.doc Page 1 Latest update 23 Jan -03
20.5 SPARE PARTS LIST
MULTI CENTER Art.No 21621
Art.Nr Identity Description Package Qty
21584 I-Front
67603 LCD Display cpl. w.Suppor Assembly
67604 PCB CPU Complete
67605 Keyboard Set
21896 Sheld Plate Internal
21897 Screw M3x10 Inox
33394- Screw M3x10 Inox
21898 Washer M3
21899 O-Ring 2,57x1,78 Sh70hr
67606 Cabel Internal
21648 Gasket bulkhead
21652-6 Cable Extern 6 m.w. conector
21653 Contact CXA female,
21587 Back Cover
21592 Bracket for Mounting
35727 Sreews for Bracket 4x10 INOX
21828 Front Protection Cover
67607 Cover Cartridge
67609 Casing
67608 Spacer
PCB Components
21768 U2 Smittrigger inverter SO 14
22063 U6 + U15 Buffer 74HCT245D TSSOP
21034 U8+ U14 IC Op Amp. Comp. LM 393P SO 8
21034 U8 IC Op Amp. Comp. LM 393P SO 8
20461 U21 Tranciever LTC1483 Bus Circuit SO 8
U22 IC 74VHCT244 Buffert Inverter TSSOP Okänd
19758 Q7 Transistor BC807-40 or 25 SOT23
19759 Q10 Transistor BC817-25 NPN SOT23
21746 D7 Diode Schottky MBRS 130LT3
D11 - D14 LED for Buttons
21895 U25- U32 LED Green for Display
22058 U25- U32 LED Orange for Display
SURFACE MOUNTED DEVICES - SMD
Components Capsule type
Resistors, capacitors 1206-07
1206-12
1206-16D
Transistors, Diodes SOT23-E1
Integrated circuits SO8
SO14
SO16
