RegB-NX2.doc Page 1 Latest update: 17 Feb -03
Introduction Table of contents
1 General Information
Related NX2/Nexus Documents, Operation Manuals
and Product Type Numbers
2 NX2 Network – Brief Introduction
2.1 Protocol
2.2 NX2/Nexus User Policy
2.3 NX2/Nexus Product type with Possible Categories
2.4 Network start up and Initialisation
3 NX2 Network Error Message with Cause and
Remedy
4 NX2 Replacement system of defect transducer and
instrument
5 NX2 Faultfinding and test on board
5.1 – 5.5 On board tests
5.6 NX2 Fault finding guide
5.7 Server NMEA communication test
5.8 Using Multi Center to find reasons of Network faults
5.9 Return of faulty NX2 units to Agent or Silva
6 NX2 Server
6.1 Block circuit diagram
6.2 Trouble Shooting – Test wave forms Server
6.3 PCB Layout with test points
6.4 Circuit Diagram
7 Log Transducer
8 Depth Transducer and System
9 Wind Transducer
9.1 Service Measures
9.2 Replacing plug connector
10 Compass Transducer
11 Multi, Speed and Autopilot Instrument
12 Wind Data and Compass Data Instrument
13 Analogue Instrument - All
14 Multi XL Instrument
15 -
16 Remote Control Instrument
17 -
18 GPS Navigator Instrument
19 GPS Antenna
20 Multi Center Instrument
21 NX2/Nexus NMEA
22 -
23 NX2 Mechanical Spare Parts and Accessories
