102TrubShotNX2.doc Page 2 Latest update: 14 Feb -03
Fault
indication
Check
signal at:
Possible
reason if not
Correct
waveform
DMM test.
Oscilloscope
Correct wave form
No output
signal
TP 6 +7
U 7 Pin 10
resp. 12
Not
possible
(pulse)
