8
Operating components
KH 2377
GB
IE
Car radio
POWER/DIM: Switch device on
and off /dim display illumination
2
MODE: Set the operating mode
3
Multi controller/SEL:
Turn to set value/volume
4
Sensor for remote control
5
Display
6
Unlocking the face plate
7
Card slot for SD/MMC cards
8
USB port
9
AUX: 3.5 mm stereo input
socket for the connection of an
external audio device
10
▸▸I: Title / Station search
forwards
11
I◂◂: Title / Station search
backwards
12
AS/PS: Automatic station
saving
13
SCAN/REC: Automatic station
search/Record to a data carrier
at the USB port or the SD/MMC
card slot
14
BAND/ENT: Select band
range/confi rm selection
15
MUTE: Switching off the sound
16
button: End call
17
button: Accept call
18
PHONE: Access telephone
function
19
DISP/#: Show display information,
# button
20
DSP/0: Adjust sound settings,
number button 0
21
PTY/9: Station search by
PTY group, number button 9
22
TA/8: Activate traffi c radio
station/ number button 8
23
AF/7: Alternative Frequency
search/regional programme
activation, number button 7
24
RDM/4: Random playback in
the CD/MP3 operation mode,
number button 4
25
INT/3: Intro function in the
CD/MP3 operation mode,
number button 3
26
RPT/2: Repeat function in the
CD/MP3 operation mode,
number button 2
27
PAU/1: Stop playback in CD/
MP3 operation, number button 1
28
OPEN: Reject disc
29
CD compartment
30
Theft protection LED/ CD
compartment position LED
31
Holder for the face plate
32
RESET: Resetting the device
33
ISO-Block connection B
34
Automotive blade type fuse 10 A
35
ISO block connection A
36
Bluetooth antenna
37
SUBWOOFER: Connection
cable with cinch connector
for subwoofer
38
Socket for microphone unit
39
LINE OUT: Audio cinch output
L/R for amplifi er
40
Antenna connection for DIN
antenna plug
Operating components
