19
DC Volt Meter (Battery #2): Displays the
voltage draw on Battery #2.
DC Main #1: Supplies 12 volt DC power
from Battery #1 to all breaker switches on
the DC side of the electrical distribution
panel.
DC Main #2: Supplies 12 volt DC power
from Battery #2 to all breaker switches on
the DC side of the electrical distribution
panel.
Cabin Lights Salon: Supplies power to the
cabin lights in the salon and galley.
Cabin Lights Forward: Supplies power to
the cabin lights in the forward stateroom
and forward head.
Courtesy Lights: Supplies power to all
courtesy lights throughout the yacht.
Cabin Lights Aft: Supplies power to the
cabin lights in the aft stateroom and aft
head.
Aft Toilet: Supplies power to the aft toilet.
Forward Toilet: Supplies power to the
forward toilet.
Fresh Water: Supplies power to the fresh
water pump.
Forward Shower Pump: Supplies power
to the forward shower sump pump.
Aft Shower Pump: Supplies power to the
aft shower sump pump.
Macerator: Supplies power to the macera-
tor pump.
Refrigerator: Supplies DC power to the
refrigerator.
Spare: Supplies power to additional acces-
sories.
Engine Room Lights: Supplies power to
the engine room lights.
Bilge Pump Fuses
and Breaker Switches
Forward Bilge Auto: Fuses the forward
bilge pump automatic switch.
Forward Bilge Manual: Supplies power
to the forward bilge pump when manually
operated.
Mid Bilge Auto: Fuses the mid bilge pump
automatic switch.
Mid Bilge Manual: Supplies power to the
mid bilge pump when manually operated.
Aft Bilge Auto: Fuses the aft bilge pump
automatic switch.
Aft Bilge Manual: Supplies power to the aft
bilge pump when operated manually.
Fuel fumes in the engine
compartment can explode. Before work-
ing on any electrical wiring, ventilate the
engine compartment and disconnect the
batteries to prevent sparking.
NEVER reset a breaker
switch which has tripped automatically
without fi rst locating and correcting the
problem. The electrical system and de-
vices may be damaged.
