SC4400/SC4200 PTT

Specifications

Supported Mic Type

Moving Coil or Condenser

(Software Configurable)

• Max Avg. Speaker Output Power

2.65W with 4 Ohm Speaker

Impedance

• MIC Bias

2.15V or 3V (Software

Configurable); Applied via a 2K

Ohm Resistor

• Recommended Speaker Impedance (Handset)

4 Ohm to 16 Ohm

• Recommended Speaker Impedance (Headset)

75 Ohm to 300 Ohm

• Recommended MIC impedance

<= 1K Ohm

• Peak Speaker Output Voltage

5.5V

• Absolute MIC Input Voltage

3.3V
