SIM7600E_SIM7600E-H-PCIE_Hardware_Design_V1.00 14 2017-11-23
Others
WA KE # /MICP 1
I/O SIM7600E-PCIE: Wake up host
SIM7600E-PCIEA: MIC positive input
If unused, keep
open.
If Analog audio is
available, wake up
function is invalid.
If Analog audio is
needed,please
consult our sales
staff, for more
information .
MICN 3
I SIM7600E-PCIE: NC
SIM7600E-PCIEA: MIC negative input
EARP 5 O
SIM7600E-PCIE: NC
SIM7600E-PCIEA: Receiver positive output
EARN 7 O
SIM7600E-PCIE: NC
SIM7600E-PCIEA: Receiver negative output
W_DISABLE# 20
I
RF Control Input
If unused, keep
open.
LED_WWAN# 42
O Network Status Indication output If unused, keep
open.
NC
6,23,25,28,31
,33,45,47,48,
49,51
-- No connection Keep open
SIMCOM CONFIDENTIAL FILE
