2.1 Hardware Interface Overview
SIM7600E-PCIE provides various hardware interfaces via Mini PCI Express card connector.
● Power Supply
● PERST#
● W_DISABLE#
● LED_WWAN#
● WA KE #
● USB Interface
● USIM Interface
● UART Interface
● I2C Interface
● Analog Audio Interface* (Only provided on PCIEA products)
