SIM7600E_SIM7600E-H-PCIE_Hardware_Design_V1.00 26 2017-11-23
5. RF Specifications
5.1 GSM/WCDMA/LTE RF Specifications
Table 15: Conducted transmission power
Frequency
Power
Min.
EGSM900
33dBm ±2dB
5dBm ± 5dB
DCS1800
30dBm ±2dB
0dBm ± 5dB
EGSM900 (8-PSK)
27dBm ±3dB
5dBm ± 5dB
DCS1800 (8-PSK)
26dBm +3/-4dB
0dBm ±5dB
WCDMA B1
24dBm +1/-3dB
<-50dBm
WCDMA B5
24dBm +1/-3dB
<-50dBm
WCDMA B8
24dBm + 1/-3dB
<-50dBm
LT E-FDD B1
23dBm +/-2.7dB
<-40dBm
LT E-FDD B3
23dBm +/-2.7dB
<-40dBm
LT E-FDD B5
23dBm +/-2.7dB
<-40dBm
LT E-FDD B7
23dBm +/-2.7dB
<-40dBm
LT E-TDD B8
23dBm +/-2.7dB
<-40dBm
LT E-FDD B20
23dBm +/-2.7dB
<-40dBm
LT E-TDD B38
23dBm +/-2.7dB
<-40dBm
LT E-TDD B40
23dBm +/-2.7dB
<-40dBm
LT E-TDD B41
23dBm +/-2.7dB
<-40dBm
Table 16: Operating frequencies
Frequency
Receiving
Transmission
EGSM900
925
～
960MHz
880
～
915 MHz
DCS1800
1805
～
1880 MHz
1710
～
1785 MHz
WCDMA B1
2110
～
2170 MHz
1920
～
1980 MHz
WCDMA B5
869
～
894 MHz
824
～
849 MHz
WCDMA B8
925
～
960 MHz
880
～
915 MHz
The LT E Operating frequencies are shown in the following table 17.
GPS
1574.4
～
1576.44 MHz
-
GLONASS
1598
～
1606 MHz
-
BD
1559
～
1563 MHz
