8.3 Sensitivity, Range and Pet immune Adjustment
The calibration of range and sensitivity is performed by single digital 16 position rotary
switch.
There are 3 groups of switch setting according to detection range.
Each group is divided to several levels of sensitivity according to installation environment.
The sensitivity is determined by a rotating switch (16 positions). Changing the sensitivity
affects immunity to environmental noises, also affects the detection distance and pet
immunity level.
The rotating switch is marked with digits from “0” to “9” and following letters from “A” to “F”.
Position “0” is maximum sensitivity and “F” is minimum sensitivity.
Note: Adjust sensitivity according to environmental conditions!
Group A - positions 0 – 7 – set sensitivity for 15m detection range with immunity to pets weight
up to 15kg – very sensitive – 1 pulse.
Group B - positions 8 – A – set sensitivity for 10m detection range with immunity to pets weight
up to 20kg – less sensitive – 2 pulses.
Group C - positions B – F – set sensitivity for 5m detection range with immunity to pets weight
up to 35kg – less sensitive – 2 pulses.
Each group is divided to 5 or 6 sub-positions that help to define the environmental
condition inside the detection range:
Low risk: very stable environment without interference like parking garage, under roof
parking space, playground, football court, service road, etc.
Risk: Stable environment with some trees, bushes, flowerpots, planters.
