11 Specifications
Detection Method
Double PIR AND MW
Microwave Frequency
24.125 GHz
Power Input
9.6 to 16Vdc
Current Draw
Active: 24mA (±5%)
Standby: 21mA (±5%)
Temp Compensation
Yes, Dual slop temperature compensation
Alarm Period
2 sec (±0.5sec)
Alarm Outputs
Form C (NC, NO, Common)
28Vdc 0.1 A with 10 Ohm
Tamper Switch(s)
Two Switches
N.C 28Vdc 0.1A with 10 Ohm Series protection resistors
Opens when cover is removed from unit’s base
Warm up Period
120sec (± 5sec)
LED Indicator
LED is ON during ALARM
RF Immunity
10 V/m plus 80% AM from 80 MHz to 2GHz
Electro Static Immunity
6kV contact, 8kV air
Transient Immunity
1kV
Operation Temp
-35ºC ~ +55ºC
Dimensions
200mm x 86mm x 80mm
Weight
500gr.
Protection Degree
IP 65
