24
A TECHNICAL SPECIFICATIONS
ELECTRICAL
Input Signals: CVBS on RCA/Phono type connector
S-VHS on Mini-DIN connector
RGBHV on DB15HD connector
RGBS / YCrCb on RCA/Phono type
connector
Horizontal frequency: from 15 to 80 kHz (up to to UXGA
format @ 60 Hz)
Vertical frequency: 48-100 Hz
Video standards : automatically selected (PAL
B,G,H, I, M,N,60, SECAM, NTSC
3.58, 4.43)
High definition video: ATSC HDTV (480p, 720p, 1080i)
Graphic standards : VGA, SVGA, XGA, SXGA, UXGA
Deinterlacer: Faroudja chip set, DCDi
™
, 3:2 pull
down sequence convertion
Colour temperature: adjustable from 5000 to 9300
degrees K
Video processor: DTI, CTI, comb filter, noise
reduction.
Sharpness, Y/C delay and NTSC
tint adjustments
Remote control: via infrared remote control and
via computer through RS232
serial interface
Low Voltage Power Output:
one 12 Vdc output, 100 mA
max on jack connectors
OPTICAL
Projection system: optical engine based on 1 DMD™
chip, sealed housing, dusty proof
DMD™ panel: resolution 1024x576 pixel
Brightness uniformity: 10% above or below the average
Contrast ratio: > 1800:1 (full On / full Off)
Projection lens: zoom, 12 elements AR multilayer
coating, motorized focus and zoom,
manual elevation
Aperture f#: 2.7 (zoom max) - 3.3 (zoom min)
Picture size: 50-250 inches (diagonal measure)
Aspect ratio: 4/3 and 16/9
Throw ratio: 2.2:1 - 3:1
(throw distance: picture width)
Focus range: 2.2 - 13.0 m (7’ 3” - 42’ 8”)
Throw Distance: 60” : 3,0m - 4,1m (10’ 0”-13’ 7”)
80” : 4,0m - 5,5m (13’ 3”-18’ 3”)
100” : 5,0m - 6,8m (16’ 7”-22’ 7”)
Keystone adjustement: up to 28° (optical: ± 10° digital: ±18°)
Lamp: 120 W UHP
Lamp life time: 6000 hours (average value measured
in the laboratory under optimal condi-
tions; it can be sensibly reduced by
the unit misusing)
