Sim2 Domino 18 - Page 5

3
6
4
1
2
3
5 8
7
C
-S
YN
C
12
11
13 17
9
10
16
19
15
14
18
20
1 Projection lens
2 Lens shift knob
3 Cooling air inlet vents
4 Remote control IR sensor
5 Cooling air outlet vents
6 Adjustable carry-handle
7 Adjustable levelling feet
8 Ceiling/wall bracket fixing holes
9 Fused power socket
10 Main power switch
11 Remote control rear IR sensor
12 Green LED
13 Red LED
14 Rear keyboard pad
15 Composite video input
16 S-Video input
17 VGA input
18 RGB / YCrCb input
19 12Vdc screen output
20 RS232 interface connector
