SFX-10 Video Mixer ___ Specifications
22
SPECIFICATIONS
Four Video Inputs
Source Inputs
Composite Video Input : x 2 (Source 1,2)
1.0Vp-p 75Ω composite signal, Pin Jacks
S-Video (Y/C Input) Input : x 2 (Source 3, 4):
Y signal: 1.0 vp-p 75Ω
C signal: 0.3Vp-p 75V, Mini Din 4-pin connector
Audio Input: x 2
-6dbv/20k Ω, Pin Jacks (L/R)
External Sound Input MIC input: x 1 (MIC); -35dbv/600 Ω, ¼”
AUX input: x 1 (AUX); -6dbv/20k Ω, Pin Jacks (L/R)
Video Output: x 2
1.0Vp-p 75Ω composite signal, Pin Jacks
Y/C Output: x 2
Recording Output
Y signal: 1.0 vp-p 75Ω
C signal: 0.3Vp-p 75V, Mini Din 4-pin connector
Audio Output: L/R x 2
-6dBs/1 kΩ Pin Jacks (L/R)
Monitor Output x 4 (monitor outputs, one for each input)
Video Output: 1.0Vp-p 75Ω composite signal, Pin Jacks
Headphone Output x 1 (Headphone); 8 Ω, 1/8” phone jack
Time base correction Dual time base correctors
Video Effects – dual channel Still, Strobe, Mosaic, Paint, Negative, Wipe, Mix, Fade, Picture-in-
Picture, Chroma key, Luminance key
Background colors White, Yellow, Cyan, Green, Magenta, Red, Blue, Black
Key Effects Chroma – blue key, adjustable key level, normal or reverse key
Luma – adjustable from black to white, normal or reverse key
Picture in Picture Three size, w/ or w/o border, any position on the screen
Wipe patterns 96 patterns
Auto wipe/fade Adjustable auto fade / wipe speed
S/N (typical) Video: 48 dB (composite), 50dB (Y/C) Audio: 60 dB
Power Source 120V (240 AC), 50/60 Hz
Power Adapter output 12VDC 1.25 A
Power Consumption Approximately 10W
Dimensions 15.6 (W) x 11.3 (D) x 2 (H) inches
Weight 4 lbs. 13 oz
