1.8 TIME CLOCK OPTIONAL (fig. 26)
Setting the time
The time of day can be set by grasping the outer edge of the
black dial and turning it in a clockwise direction until the cor-
rect time is in line with the white pointer.
Setting the “switching time”
The “ON” periods are set by sliding the blue tappets, adjacent
to the time periods required, to the outer edge of the dial.
The tappets that remain at the centre of the dial will be the
“OFF” periods.
N.B.: The smallest switching time (ON or OFF) is 15 minutes.
– To select “Timed” mode move the selector switch in the
middle of the clock face to the “”position.
– To select “Constant” mode move the selector switch in the
middle of the clock face to the “I” position.
– To select “OFF” mode move the selector switch in the mid-
dle of the clock face to the “O” position.
27
