SIME FORMAT WALL HUNG BOILERS
MODEL 34i AND MODEL 34e
REF: INSTALLATION INSTRUCTIONS 19/02/04
4
SIME FORMAT WALL HUNG BOILERS
MODEL 34i, MODEL 34e
CENTRAL HEATING BOILERS
INSTALLATION INSTRUCTIONS
INTRODUCTION
These instructions cover the installation of the SIME FORMAT 34i, an internally
mounted boiler using a co-axial flue system, and the SIME FORMAT 34e, an
externally mounted boiler. They are fully automatic in operation, being fitted with
direct fired ignition, modulating temperature control and safety control by means of
electronic and electro-mechanical devices, integrated with a custom-designed
P.C.B..
The central heating output range is adjustable between 11.2 KW and 34 KW.
NOTE: THE BOILER IS NOT TO BE USED FOR POOL OR SPA
HEATING.
THE BOILER MUST BE INSTALLED ONLY BY AN
AUTHORISED PERSON
1.0 GENERAL INFORMATION
1.0.1 Related Documents
The boilers must be installed strictly in accordance with these
Instructions, the Australian Gas Association “Gas Installation Code”
AG601, Local Water and Electricity Authority Requirements and all
State and Local Government Regulations which may be applicable.
1.0.2 Delivery Check
The Installer shall, upon delivery, immediately remove all
packaging materials, and inspect the appliance for any
damage, and ensure that the boiler is equipped for the gas to
which it is to be connected. Report to the supplier any
discrepancies and / or damage, quoting the model number
and serial number, which can be found on the appliance Data
Plate.
