Sime Format 34i User Manual

SIME FORMAT WALL HUNG BOILERS
MODEL 34i AND MODEL 34e
REF: INSTALLATION INSTRUCTIONS 19/02/04
6
Fig 3.
Key
1. Fan 11. Circulation Pump
2. Water-gas exchanger 12. Expansion Vessel
3. Combustion chamber 13.Safety Valve
4. Gas Valve 14. Drain Plug
5. Limit thermostat 85o C 15. Automatic By-pass
6. 102o C safety Thermostat C. Filling Connection
7. NTC sensor G. Gas Connection
8. Hydrometer M. C.H.Flow
9. Water Flow Switch S. Discharge Safety Valve
10. Air Relief Valve R. C.H.Return

Sime Format 34i Specifications

General

Brand	Sime
Model	Format 34i
Category	Boiler
Language	English
