Installation/Operation/Parts

For further operating, installation, or

maintenance assistance:

Call 1-800-468-7867

English. . . . . . . . . . . Pages 2-12

Installation/Fonctionnement/Pièces

Pour plus de renseignements

concernant l’utilisation,

l’installation ou l’entretien,

Composer le 1 (800) 468-7867

Français. . . . . . . . . Pages 13-23

Instalación/Operación/Piezas

Para mayor información sobre el

funcionamiento, instalación o

mantenimiento de la bomba:

Llame al 1-800-468-7867

Español . . . . . . . Paginas 24-36

© 2011 SIM922 (4/5/11)

293 Wright Street, Delavan, WI 53115

Phone: 1-800-468-7867

Fax: 1-800-390-5351

Web Site: SimerPump.com

3105P, 3107P, 3110P 4807S, 4810S

OWNER’S MANUAL

Shallow Well Jet Pumps

NOTICE D’UTILISATION

Pompes à éjecteur

pour puits peu profonds

MANUAL DEL USUARIO

Bombas de chorro para pozos

poco profundos

Questions and Answers

P
Patricia JohnsonAug 7, 2025
Why won't my Simer 3110P Water Pump motor run?
- M
  maxparrishAug 7, 2025
  Your Simer Water Pump motor might not be running because the disconnect switch is off. Ensure the switch is turned on. Another possible reason is a blown fuse or tripped circuit breaker, in which case you should replace the fuse or reset the circuit breaker. A defective starting switch, loose or disconnected wires, or dirty pressure switch contacts could also be the cause. To address these, disconnect the power before replacing the starting switch, checking and tightening the wiring, or filing the pressure switch contacts with an emery board or nail file.
X
xcamposAug 17, 2025
Why does my Simer Water Pump motor run hot and the overload kicks off?
- J
  josephwarnerAug 17, 2025
  If your Simer Water Pump motor runs hot and the overload kicks off, it could be due to incorrect wiring. Refer to the wiring instructions to ensure it's properly connected. Low voltage can also cause this issue, so check with your power company. Additionally, too frequent cycling of the pump may be the cause; consult the section on too frequent cycling for solutions.
J
Jessica DiazAug 27, 2025
Why doesn't my Simer Water Pump deliver water to full capacity?
- J
  James SampsonAug 27, 2025
  If your Simer Water Pump isn't delivering water to its full capacity, the water level in the well may be lower than estimated; a deep well jet will be needed if your well's depth to water is more than 25 feet. If you're using steel piping, it may be corroded or limed, causing excess friction; replace it with plastic pipe where possible, or with new steel pipe. The piping may also be too small, so use larger piping. Finally, the well point may be packed; backflush the well point or sink a new one.
Q
qdayAug 31, 2025
Why is my Simer Water Pump causing air spurts from the faucets?
- D
  Dylan FranklinSep 1, 2025
  Air spurts from the faucets connected to your Simer Water Pump can occur if the pump is picking up prime; when the pump has picked up prime, it should pump solid water with no air. Another cause could be a leak in the suction side of the pump; check joints for leaks with soapy water. If the well is gaseous, consult the factory about installing a sleeve in the well. Intermittent over-pumping of the well, where water is drawn down below the foot valve, can also cause this; lower the foot valve if possible, otherwise restrict pump discharge.
W
William JohnsonNov 10, 2025
What to do if my Simer Water Pump delivers water but doesn't shut off or cycles too frequently?
- P
  Paula YorkNov 10, 2025
  If your Simer Water Pump is delivering water but doesn't shut off or cycles too frequently, several factors could be responsible. The pressure switch may be out of adjustment or its contacts might be welded together; in this case, disconnect the power and adjust or replace the pressure switch. Also, check if any faucets have been left open and close them. A clogged venturi, nozzle, or impeller can also cause this issue, so clean these components. Other potential causes include a waterlogged standard pressure tank with no air cushion (drain the tank to the air volume control port), leaking pipes (check all connections for air leaks), leaking foot valves (replace the foot valve), or an air charge that is too low in the pre-charged tank (check the air pressure at the valve stem using a tire p...
K
kaitlyn00Nov 21, 2025
What to do if my Simer 3110P Water Pump motor runs but no water is delivered?
- W
  Whitney KnappNov 21, 2025
  If the Simer Water Pump motor runs but no water is delivered, consider the following: * If it's a new installation, re-prime the pump according to the instructions, and check all connections on the suction line, AVC, and ejector for air leaks using soapy water or shaving cream. Replace the foot valve or check valve if they are leaking. * If the pump has lost prime, check all connections on the suction line and shaft seal for air leaks. Lower the suction line into the water and re-prime if the water level is below the suction pipe inlet. * Also, check if the foot valve, strainer, ejector, or impeller are plugged and clean them. Replace the check valve or foot valve if they are stuck shut. Thaw the pipes if they are frozen. Ensure the foot valve and/or strainer are not buried in sand ...

Summary

Owners Manual

Shallow Well Jet Pumps

Manual for Simer Shallow Well Jet Pumps, covering installation, operation, and maintenance.

Safety Information

Important Safety Instructions

Essential instructions for safe installation, operation, and maintenance.

Electrical and General Safety

Covers electrical hazards and general safe operating practices.

Warranty Details

Limited Warranty and Exceptions

Outlines the 12-month limited warranty, exceptions, and general terms and conditions.

Installation Guide

Replacing an Old Pump

Procedure for removing an old pump and installing a new one.

Well Point Installation

Cased Well Installation

Electrical Setup

Motor Switch Settings

Voltage Selector Operation

Wiring and Electrical Specifications

Wiring Connections Procedure

Wire and Fuse Size Chart

Troubleshooting

Common Pump Operational Issues

Simer 3110P Specifications

General

Brand	Simer
Model	3110P
Category	Water Pump
Language	English
