This section describes mounting the 4010-9908 in 4010ES Back Boxes.
The 4010-9908 4-Point AUX Relay Card (Figure 10) is designed to be mounted on the PDI card in
a 4010ES panel. The card can be mounted on any of the PDI blocks, provided it fits inside the
available space. Use connector P1, labeled on the rear of the card, to connect to the PDI block.
Figure 4. 4010-9908 4-Point AUX Relay Card
See section “4100-3204 Wiring’’ later in this document for information on the wiring of the 4010-
9908 card.
