Simplex 4010ES Quick Start Guide

3 S4100-0059-4, 3/2012
MX Loop Interface Module
Model Description
4100-6077 MX Loop interface module for 4100ES and 4100U fire alarm control panels
4010-9917 MX Loop interface module for 4010ES fire alarm control panels
Compatible Peripherals
Addressable Smoke and Heat Sensors and Accessories
Model Description MX Model Reference Data Sheet Reference
4098-5201 Heat Sensor 801H
S4098-0045
4098-5202 Photoelectric Smoke Sensor 801P
4098-5203 Photoelectric Smoke Sensor with Heat Sensor 801PH
4098-5207 5” Sensor Base with Remote LED Output 5B-UL
4098-5208 5” Isolator Base with Remote LED Output 5BI-UL
4098-5209 Loop Powered (LP) Sounder Base, 85 dB @ 3 ft (1 m) 802SB
4098-5210 Loop Powered (LP) Sounder Base, 85 dB @ 10 ft (3 m) 812SB
4098-5211 4-Wire Sounder Base 912SB
4098-5275 6” Adapter for the 5” Base 6A-5B-UL
2098-9808 Remote LED Alarm Indicator –
4098-5276 Address Flags (pack of 100) 800F
4098-5277 Address Flag Labels –
4098-5214 Duct Housing and Accessories – S4098-0046
Addressable Manual Stations and Callpoints
Model Description MX Model Reference Data Sheet Reference
4099-5201 Single Action Manual Station –
S4099-0003
4099-5202 Double Action Manual Station –
4099-5203 Indoor Callpoint with LED (Breakglass) CP820
S4099-0004
4099-5204 Outdoor Callpoint with LED (Breakglass) CP830
Addressable Interface Modules
Model Description MX Model Reference Data Sheet Reference
4090-5201 Mini-IAM, supervised contact monitoring module MIM800
S4090-0012
4090-5202 Dual Input IAM, dual supervised contact monitoring module CIM800
4090-5203 Relay IAM RIM800
4090-5204 Signal IAM SNM800
4090-5205
Monitor ZAM; Note: For conventional devices requiring
25 VDC power, use Voltage Regulator Module 4100-5130 for
4100ES/4100U or 4010-9916 for 4010ES fire alarm control
panels
DIM800
4090-5206 Line Isolator Module LIM800
4090-5213 Addressable Module Cover M520
Device Accessories and Service Tools
Model Description
4100-5130
4100ES/4100U Voltage Regulator Module, 25 VDC nominal; isolated and resettable output; includes earth
detection circuit and trouble relay for status monitoring
4010-9916
Same as above for 4100ES/4100U
516.800.917 MX Sensor Head Removal Tool, ref. MX Model 800RT
516.800.918 MX Service Tool, ref. MX Model 801AP
516.800.922 MX Ancillary Program Lead (Spare)
516.800.923 MX Service Tool Accessory Kit
Product Selection and Peripherals Reference
