5 S4100-0059-4, 3/2012
MX Loop Output Reference
MX Loop Output
Voltage 40 VDC maximum
Current 500 mA maximum
Addresses per Loop 250 Maximum
4100ES/4100U Panel Capacity up to 30, 4100-6077 MX Loop Modules Maximum
4010ES Panel Capacity Up to 4, 4010-9917 MX Loop Modules Maximum
Loop Distance
6560 ft (2000 m) typical maximum
Note: Wire lengths may be longer depending on wiring characteristics and other conditions,
consult your Simplex product representative for additional details
Loop Resistance
150 maximum
Loop Capacitance 0.2 µF maximum
Loop Inductance 1.5 mH maximum
Communications Voltage 40 V peak maximum
Module Power Requirements
Module Voltage 24 VDC nominal, supplied from control panel power supply
Module Input Current
100 mA for module only (no devices)
1235 mA maximum, fully loaded at 250 devices; actual current depends on connected devices
LED Status Indicators (yellow LEDs)
COMM LOSS On steady upon loop communications loss, flashing if not communicating with panel
EARTH FAULT On steady when an earth fault is detected on field wiring
Loop Status LED
On steady if no device response
Slow flash if Class A open trouble
Fast flash if short circuit trouble
MX DOWNLOAD On steady when module is in service mode and download is in progress
LPS FAULT On steady upon loop power supply failure
4100-5130 or 4010-9916 Voltage Regulator Module
Input Voltage System supplied 24 VDC
Input Current Supervisory = 3 A max. with 2.5 A output load; Alarm = 4.9 A max. with 4 A output load
Output Voltage 22.8 to 26.4 VDC (25 VDC nominal); output is resettable, will track state of RESET input
Output Current 2.5 A maximum supervisory; 4 A maximum alarm
Ripple 600 mV pk-pk maximum
Trouble Relay
1 Form C dry contact for monitoring; rated 400 mA @ 30 VDC; changes state for Earth or output
voltage trouble; normally held energized
Mounting Requirements
4100ES/4100U
4 x 5 single block module; requires mounting in same bay as connected power
supply
4010ES 4 x 5 single block module
General Specifications
Mounting 4” x 10” (102 mm x 254 mm) module requires two vertical 4 x 5 block spaces
Operating Temperature Range
32 F to 120 F (0 C to 49 C)
Operating Humidity Range Up to 93% RH, non-condensing @ 90° F (32° C)
Output Wiring Connections On-board terminal blocks for field wiring 18 to 12 AWG (0.82 mm
2
to 3.31 mm
2
)
Specifications
