Simplex 4100 Series Installation Instructions

15
 Compatible appliances for NACs are shown in Table 7:
Table 7. Compatible Appliances and Accessories (for Special Application NACs)
P/N Description P/N Description P/N Description
4904-9168 V/O 15CD RED FREE-RUN TNA 4906-9102 V/O 15/30/75/110cd C/M RED TNA 4903-9253 A/V 24VDC 30CD RED HOR F/S
4904-9171 V/O 15CD WHITE FREE-RUN TNA 4906-9103 V/O 15/30/75/110cd W/M WHT TNA 4903-9254 A/V 24V 110CD RED HOR F/S
4904-9176 V/O 24VDC 15CD RED VER F/S 4906-9104 V/O 15/30/75/110cd C/M WHT TNA 4903-9255 A/V 24VDC 15CD RED VER F/S
4904-9177 V/O 24VDC 15CD WHT VER F/S 4903-9356 S/V 15CD RED 25/70V TNA 4903-9256 A/V 24V 110CD RED VER F/S
4904-9178 V/O 24VDC 15CD RED HORIZ F/S 4903-9359 S/V 15CD WHITE 25/70V TNA 4903-9257 A/V 24VDC 15CD WHT HOR F/S
4904-9183 V/O 24VDC 15CD RED CEIL F/S 4903-9150 S/V 24VDC 15CD RED HORIZ F/S 4903-9258 A/V 24VDC 30CD WHT HOR F/S
4904-9331 V/O 15CD RED SYNC TNA 4903-9153 S/V 24VDC 15CD RED VER F/S 4903-9417 A/V 15CD RED SYNC TNA
4904-9342 V/O 15CD WHITE SYNC TNA 4903-9193 S/V 24VDC 15CD WHT HORIZ F/S 4903-9418 A/V 75CD RED SYNC TNA
4904-9345 V/O 24VDC 15CD WHT PLAIN F/S 4903-9196 S/V15CD RND 4903-9419 A/V 110CD RED SYNC TNA
4904-9174 V/O 24VDC 30CD RED VER F/S 4903-9148 S/V 24VDC 30CD RED HORIZ F/S 4903-9425 A/V 15CD RED STD TNA
4904-9180 V/O 24VDC 30CD RED HORIZ F/S 4903-9194 S/V 24VDC 30CD WHT HORIZ F/S 4903-9426 A/V 75CD RED STD TNA
4904-9184 V/O 24VDC 30CD RED CEIL F/S 4903-9197 S/V, 30CD, RND TNA 4903-9427 A/V 110CD RED STD TNA
4904-9346 V/O 24VDC 30CD WHT PLAIN F/S 4903-9357 S/V 75CD RED 25/70V TNA 4903-9428 A/V 15CD WHITE SYNC TNA
4904-9169 V/O 75CD RED FREE-RUN TNA 4903-9360 S/V 75CD WHITE 25/70V TNA 4903-9429 A/V 75CD WHITE SYNC TNA
4904-9172 V/O 75CD WHITE FREE-RUN TNA 4903-9358 S/V 110CD RED 25/70V TNA 4903-9430 A/V 110CD WHITE SYNC TNA
4904-9332 V/O 75CD RED SYNC TNA 4903-9361 S/V 110CD WHITE 25/70V TNA 4903-9431 A/V 15CD WHITE STD TNA
4904-9343 V/O 75CD WHITE SYNC TNA 4903-9198 S/V 110CD, RND TNA 4903-9432 A/V 75CD WHITE STD TNA
4904-9170 V/O 110CD RED FREE-RUN TNA 4906-9151 S/V 15/30/75/110cd W/M RED TNA 4903-9433 A/V 110CD WHITE STD TNA
4904-9173 V/O 110CD WHITE FREE-RUN TNA 4906-9153 S/V 15/30/75/110cd W/M WHT TNA 4906-9127 A/V 15/30/75/110cd W/M RED
4904-9175 V/O 24VDC 110CD RED VER F/S 4906-9154 S/V 15/30/75/110cd C/M WHT TNA 4906-9129 A/V 15/30/75/110cd W/M WHT
4904-9181 V/O 24VDC 110CD WHT VER F/S 4901-9820 HORN 24VDC RED TNA 4906-9128 A/V 15/30/75/110cd C/M RED
4904-9182 V/O 24VDC 110CD RED HOR F/S 4901-9822 HORN 24VDC RED 4906-9130 A/V 15/30/75/110cd C/M WHT
4904-9185 V/O 24VDC 110CD RED CEIL F/S 4009-9201 NAC EXTENDER 120VAC, IDNET 4905-9815 SMARTSYNC ADAPTER, TNA
4904-9333 V/O 110CD RED SYNC TNA 4009-9301 NAC EXTENDER, 240VAC, IDNET 4905-9938 SMARTSYNC CTL MODULE
4904-9344 V/O 110CD WHITE SYNC TNA 4009-9401 4009 T/A ADDR CONTROLLER 4090-9005 SRP
4906-9101 V/O 15/30/75/110cd W/M RED TNA 4903-9252 A/V 24VDC 15CD RED HOR F/S 4090-9006 SRP w/ENCLOSURE
4906-9105 V/O Weatherproof W/M, RED 4906-9113 V/O Weatherproof W/M, (Can) RED 4906-9132 A/V Weatherproof, W/M, WHT
4906-9106 V/O Weatherproof W/M, WHT 4906-9131 A/V Weatherproof, W/M, RED 4906-9143 A/V Weatherproof, W/M, RED
4906-9109 HiCandela W/M V/O, RED 4906-9139 HiCandela W/M A/V, RED 4906-9140 HiCandela C/M A/V, RED
4906-9111 HiCandela W/M V/O, WHITE 4906-9141 HiCandela W/M A/V, WHITE 4906-9142 HiCandela C/M A/V, WHITE
4906-9110 HiCandela C/M V/O, WHITE 4906-9112 HiCandela C/M V/O, RED
Continued on next page
NAC Field Wiring, Continued
Guidelines
