Simplex 4100ESi Installation Instructions

Step 1: Installing the MX Digital Loop Card
5 LT0638 Iss 1.1 7/2017
In 15U and 8U cabinets utilising the short PDI backplane (PA1098) the 4100-6077AU
MX Digital Loop Card is mounted onto the short PDI backplane using the same mounting
screws included with the Loop Card kit. For increased density, two 4100-6077AU cards
can be mounted on a ME0516 Legacy/Dual Bracket in either the 8U or 15U cabinets.
The ME0516 bracket is not suitable for mounting 4100-6077AU cards in the standard
Simplex expansion bay.
The earlier 4100-6077LIM version of the loop card should not be mounted on the
ME0516 Legacy/Dual Bracket (ME0516), as the resulting module width is too wide and
may interfere with other modules and equipment.
Installation of the
4100-6077
in a 8U/15U
Cabinet
