1692863 48” Mower Deck - [SN 1 to 59999]
1693122 48” Mower Deck - [SN 1 to 59999]
1693252 48” Mower Deck (Exp) - [SN 1 to 59999]
1693420 48” Mower Deck (Exp) - [SN 1 to 59999]
55
TP 400-2215-01-LG-SMA
48” Mower Roller Bar Group - (Serial Nos. 1 to 59999)
1 1715926 1 ROCKER SHAFT ASSEMBLY
2 1931353 2 CARRIAGE BOLT, 3/8-16 x 1-3/4
3 1960071 2 WASHER, 3/8
4 1931350 12 CARRIAGE BOLT, 3/8-16 x 1
5 1916965 12 LOCKWASHER, 3/8
6 1916950 12 NUT, Hex, Full, 3/8-16
7 1924940 4 WASHER, Plain, 3/8
8 1716982 1 BRACKET, Roller, RH
9 1677507 2 SLIDE
10 1924361 2 WASHER, 1/2 x 1-1/4
11 172622 2 BOLT, Shoulder
12 1704082 2 NUT, Adjuster, Eccentric
13 1715882 1 BAR ASSEMBLY, Roller, LH
14 1928721 2 SET SCREW, Sqr Hd, 5/16-18 x 1/2
15 1715930 1 SHAFT, Roller
16 1960201 14 WASHER, 1.0
17 1678043 7 ROLLER ASSEMBLY
18 1677762 14 BUSHING, Roller
19 1701873 7 SPACER, Short
20 1918459 1 PIN, Cotter
21 158399 1 E-RING, 1/2
22 1960027 1 WASHER, Flat, 1/2 x 7/8
23 1714760 1 WHEEL, Slide
24 1716343 1 BAR ASSEMBLY, Wheel
25 1960074 1 HAIRPIN
26 1708298 1 HITCH PIN, 3/8
27 1921210 1 CAPSCREW, Hex Hd, 3/8-16 x 1
28 1919439 1 NUT, Hex, Nylon Lock, 3/8-16
29 1716341 1 BAR ASSEMBLY, Roller, RH
30 1716983 1 BRACKET, Roller, LH
31 1717583 1 DECAL, Cutting Height Indicator
32 1716480 1 PLATE, Height Indicator
33 1929000 1 CAPSCREW, Hex Hd, Taptite, 1/4-20 x 3/8
34 1716481 1 ROD, Indicator
35 1924856 1 CAPSCREW, Hex Hd, Taptite, 5/16-18 x 1/2
36 1931355 2 CARRIAGE BOLT, 3/8-16 x 2-1/4
37 1676088 2 SPACER
38 1676087 2 STRAP
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
