Simplicity 2000 Series - Drive Shaft - SERVICE PARTS

1
2
33
4
5
5
4
Capscrew used to
mount Gauge Wheels
- see 60" Mower
Housing, Cover &
Gauge Wheel Group.
Hardware used to
mount Stone Guard -
see 60" Mower
Deflector & Stone
Guard Group.
Capscrew used to
mount Gauge Wheels
- see 60" Mower
Housing, Cover &
Gauge Wheel Group.
88
TP 400-2215-01-LG-SMA
© Copyright 2000 Simplicity Manufacturing, Inc. All Rights Reserved.
60” Mower - Baffles (Export Models)
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
A-LG42840A
The above parts group applies to the following Mfg. Nos.:
1693253 60” Mower Deck (Exp)
1693445 60” Mower Deck (Exp)
1697642 Legacy 60” Baffle Kit
