Simplicity 2000 Series User Manual

87
TP 400-2215-01-LG-SMA
60” Mower Deflector & Stone Guard Group
1 1916950 5 NUT, Hex, Full, 3/8-16
2 1916965 5 LOCKWASHER, 3/8
3 1700343 1 ROD, Hinge
4 1702451 1 DEFLECTOR ASSEMBLY
5 1931350 5 CARRIAGE BOLT, 3/8-16 x 1
6 1700186 1 STONE GUARD
7 1673655 1 BRACKET, Hinge
8 1676213 1 SPRING, Torsion
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1692860 60” Mower Deck
1693123 60” Mower Deck
1693253 60” Mower Deck (Exp)
1693445 60” Mower Deck (Exp)
