1692863 48” Mower Deck
1693122 48” Mower Deck
1693252 48” Mower Deck (Exp)
1693420 48” Mower Deck (Exp)
59
TP 400-2215-01-LG-SMA
48” Mower Baffle & Inner Roller Group
1 1923362 2 NUT, Hex, Center Lock, 5/16-18
2 108454 1 BRACKET & SHAFT ASSEMBLY, Inner
3 1668513 2 ROLLER ASSEMBLY
4 1960020 2 WASHER, Plain, 5/8
5 1918458 2 PIN, Cotter
6 1917372 4 NUT, Hex, Full, 5/16-18
7 1917356 4 LOCKWASHER, 5/16
8 108224 1 BRACKET, Inner, LH
9 1931333 4 CARRIAGE BOLT, 5/16-18 x 3/4
10 1674774 1 BAFFLE ASSEMBLY
11 1679385 2 SCREW-HOOK, Baffle
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
