65
TP 400-2215-01-LG-SMA
48” Mower - Baffles (Export Models)
1 1718566 1 BAFFLE, RH
2 1718565 1 BAFFLE, LH
3 1931350 3 CARRIAGE BOLT, 3/8-16 x 1
4 1916965 3 LOCKWASHER, 3/8
5 1916950 3 NUT, Hex, Full, 3/8-16
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1693252 48” Mower Deck (Exp)
1693420 48” Mower Deck (Exp)
1687641 Legacy 48” Baffle Kit
