PTO Switch
-
gages attachments that use the PTO. To engage the PTO,
pull UP on the switch. Push DOWN to disengage. Note that
Ignition Switch
The ignition switch starts and stops the engine, it has three
positions:
electrical system.
RUN Allows the engine to run and powers the
electrical system.
START Cranks the engine for starting.
Ground Speed Pedals
The tractor’s forward ground speed is controlled by the
forward ground speed control pedal. The tractor’s reverse
ground speed is controlled by the reverse ground speed
control pedal.
Depressing either pedal will increase ground speed. Note
that the further down the pedal is depressed, the faster the
tractor will travel.
Cruise Control
The cruise control is used to lock the ground speed control
Mower Height of Cut Adjustment
The mower cutting height adjustment lever controls the
mower cutting height. The mower cutting height can be set
to one of seven positions between 1.5” and 4.0” (3,8 and
10,2 cm).
Seat Adjustment Lever
The seat can be adjusted forward and back. Move the
lever, position the seat as desired, and release the lever
to lock the seat into position.
Transmission Release Lever
The transmission release lever deactivates the trans-
mission so that the tractor can be pushed by hand. See
Pushing the Tractor by Hand section.
Fuel Tank
To remove the cap, turn counterclockwise.
Fuel Level Gauge
Displays the fuel level in the tank.
Parking Brake
The parking brake knob is used to lock the parking brake
when the tractor is stopped. Fully depressing the brake
pedal and pulling up on the knob engages the parking
brake.
Brake Pedal
Depressing the brake pedal applies the tractor brake.
13
