Attaching a Trailer
The maximum horizontal drawbar force allowed is 65 lbs
(280 N). The maximum vertical drawbar force is 35 lbs
(160 N). This equates to a 250 lbs (113 kg) trailer on a 10
degree hill.
Stopping the Tractor and Engine
1. Return the ground speed control(s) to NEUTRAL.
2. Disengage the PTO and wait for all moving parts to
stop.
3. Move the throttle/choke control to the SLOW position.
4. Turn the ignition key to OFF. Remove the key.
WARNING
Fuel and its vapors are extremely
Fire or explosion can cause severe burns
or death.
Figure 6
Adjusting Mower Cutting Height
The cutting height lift lever (A, Figure 6) controls the
mower cutting height. The cutting height is has seven
positions between approximately 1.5” and 4.0” (3,8 and
10,2 cm).
A
