Simplicity Regent - Features & Controls; Hydro Model Controls; Gear Model Controls

6
CONTROLS - HYDRO MODEL
CONTROLS - GEAR MODEL
Features & Controls
Figure 2. Tractor & Mower Controls - Hydro Model
Figure 3. Tractor & Mower Controls - Gear Model
A. Steering Wheel
B. Engine Throttle Control
C. Parking Brake Knob
D. Ignition Key/Switch
E. Headlight Switch
F. PTO (Electric Clutch) Switch
G. Mower Height Adjustment Lever
H. Brake Pedal
I. Forward Direction Pedal
J. Rear Direction Pedal
A. Steering Wheel
B. Engine Throttle Control
C. Parking Brake Knob
D. Ignition Key/Switch
E. Headlight Switch
F. PTO (Electric Clutch) Switch
G. Mower Height Adjustment Lever
H. Clutch/Brake Pedal
I. Gear Selector
A
H
I
G
F
E
D
A
H
G
E
I
F
C
B
D
C
J
B
