Safety Decals
This unit has been designed and manufactured to pro¬
vide you with the safety and reliability you would expect
from an industry leader in outdoor power equipment
manufacturing.
Although reading this manual and the safety instructions
it contains will provide you with the necessary basic
knowledge to operate this equipment safely and effec¬
tively, we have placed several safety labels on the unit to
remind you of this important information while you are
operating your tractor.
All WARNING, CAUTION and instructional messages on
your tractor and mower should be carefully read and
obeyed. Personal bodily injury can result when these
instructions are not followed. The information is for your
safety and it is important! The safety decals shown below
are on your tractor and mower.
If any of these decals are lost or damaged, replace them
at once. See your local dealer for replacements.
These labels are easily applied and will act as a constant
visual reminder to you, and others who may use the
equipment, to follow the safety instructions necessary for
safe, effective operation.
OPERATION
CHOKE IGNITION SWITCH
• TO START ENGINE SEAT MUSI BE OCCUPIED GROUND SPEED CONTROL
LEVER IN NEUTRAL ANO PTO SWITCHES) OFF
N
OFF
• WHEN OPERATOR LEAVES SEAT
V ENGINE WILL SHUT OFF WITH GROUND SPEED CONTROL LEVER IN
FORWARD OR REVERSE. OR WITH PTO SWITCHES) ON
START
• TO OPERATE PTO CLUTCHES!
1 THE OPERATOR MUST BE IN SEAT.
2 TO ENCACE PTO PULL PTO SWITCKTESl UP
3 TO OiSENGAGE PTO. PUSH SWITCH(ES) DOWN
PULL TO CHOKE
2 SPEED AXLE SHIFT
t.
Ht RANGE ^
NEUTRAL
3
t
tO HANGE
:-,V
TO SET PARKING BRAKE
! LOCK FOOT PEDALS TOGETHER
2 PULL KNOB OUT WHILE PEDALS AHE DEPRESSED
3 RELEASE FOOT PEDALS WHILE HOLDING KNOB OUT
TO RELEASE PARKING BRAKE
FOOT PEDALS
2 TO ASSIST TURNING UH
TRACTION. DEPRESS PEOAlS
INDIVIDUALLY
( WMEF1 i
IRAKI ^ P'l
'
CAIJT10H: SHIFT 2 SPEED AXLE TO NEUTRAL BEFORE TOWING. TOWING M GEAR WHO. RESULT M
DAMAGE TO HYDROSTATIC TRANSMISSION. DO NOT TOW AT SPEED GREATER THAN S MPH.
Decal - Console (20 HP Model shown)
Part No. 1714633 -18 HP Model
Part No. 1714160 - 20 HP Model
rAwBn
FRONT P.T.O. SHIELD IS PROVIDED TO
HELP PREVENT PERSONAL INJURY AND
PROTECT BELT DRIVE. KEEP SHIELD IN
PLACE WHEN FRONT MOUNTED
ATTACHMENTS ARE NOT BEING USED.
Decal - PTO Shield
Part No. 1679117
A WARNING
CONNECT GROU OQTERM NAL WHEN WORKING ON ELECTRICAL SYSTEM TO PREVENT SHORT
flWWT. toprevent„possible; damage to electrical components, never disconnect
IS MNNING AND BE SURE BATTERY TERMINALS ARE TIGHT BEFORE
SI AKIINu ENGINE.
Decal - Battery Warning
Part No. 1679675
A DANGER
A DANGER
ROTATING CUTTING BLADE
DO NOT PUT HANDS
OR FEET UNDER
MOWER DECK WHILE
BLADE IS ROTATING.
Decal - Danger
Part No. 1704276
ROTATING CUTTING BLADE .
DO NOT OPERATE MOWER
WITHOUT DEFLECTOR
OR ENTIRE GRASS
CATCHER IN PLACE.
Decal • Danger
Part No. 1704277
