11 - ENG
• Your washer operates at fluid pressures and velocities high enough to
penetrate human and animal flesh, which could result in amputation or other
serious injury. Leaks caused by loose fittings or worn or damaged hoses can
result in injection injuries. DO NOT TREAT FLUID INJECTION AS A SIMPLE
CUT! See a physician immediately!
pRESSURE WASHER OpERATING FEATURES
HOW TO USE SpRAY WAND
Refer to the following chart to choose the correct nozzle for the job to be performed.
NOzzLE COLOR SpRAY pATTERN USES
Yellow
15˚
intense cleaning of small areas
Green
25˚
intense cleaning of larger areas
Black
low pressure
applies cleaning solutions
Turbo Spray
Nozzle
delivers the optimal cleaning effect
for the toughest cleaning tasks
NOTE: The pressure of the spray on the surface you are cleaning
increases as you move the wand closer to the surface.
*NOTICE: The high pressure spray from your pressure washer is capable
of causing damage to surfaces such as wood, glass, automobile paint,
auto striping and trim, and delicate objects such as flowers and shrubs.
Before spraying, check the item to be cleaned to assure yourself that it
is strong enough to resist damage from the force of the spray.
CHANGING NOzzLES ON SpRAY WAND (FIG. 4)
DANGER: Risk of fluid injection. Do not direct discharge stream toward
persons, unprotected skin, eyes or any pets or animals. Serious injury will
occur.
WARNING: Flying objects could cause risk of serious injury. Do not attempt
to change nozzles while pressure washer is running. Turn pressure washer off
before changing nozzles.
1. Pull quick-connect coupler back and insert nozzle (S).
4
S
2. Release quick-connect coupler and twist nozzle to make
sure it is secure in coupler.
WARNING: Flying object could cause risk of serious
injury. Ensure nozzle is completely inserted in quick-
connect socket and quick-connect snap ring is fully engaged (forward) before
squeezing gun trigger.
