6. PROGRAMMING
6.1 Programming Order
The following parameter order is recommended to change the display from the
default values. Parameters entered in any other order may cause unexpected
results.
G3- Always change the decimal point location first, to the desired display range. The
decimal point will then be in the proper position for setting setpoints or linearization.
Magnifying the display from 10 to 100 is as simple as moving the decimal point.
/LQ- Linearization affects the setpoints and analog-out results. If decimal point
location is changed, it will display in the wrong place for electrical input, but in the
desired location for output display.
The setpoints follow the displayed results of any linearization or decimal
point settings and not necessarily the electrical input.
$RX7 - The analog-out “Hi and Lo” settings also track the display results from the
above changes and not the electrical input.
6.2 General Programming Guidelines
Changes can be made while programming, unless the outputs or relay alarms are
critical to operation.
1. Press
to move in and out of the main programming.
2. Press
or to scroll to desired submenu. Press REs to enter a submenu.
Press
to scroll back to main menu.
3. To change a flashing parameter press REs and press
, or . To save
the
change and proceed to the next change, press .
NOTE: ALWAYS SAVE CHANGES! Improperly saved changes will be lost if
power fails.
4. Press REs after making the last change, then return to run mode by pressing
while in main menu mode. “XSGW)/6+” will display before displaying run
mode.
6.3 Programming Menu
Available menu choices depend on the operator’s password rights. Use caution
when changing values “on the fly” because relay changes are immediate upon
exiting menus. While in local menu, RS-485 communications will halt to avoid
command conflict. When in local or remote menu, relay and alarm operations are
suspended. If left in menu mode the local or remote menu will “time out” in two
minutes then resume normal operation.
