PRODUCT DESCRIPTION2.
FRONT VIEW BACK VIEW
1
7
8
2
3
4
6
5
WASHING MACHINE PARTS
2.1
1
2
Control Panel
PARTS LISTINSIDE VIEW
3
4
Lid
5
Cabinet
Levelling Adjustable Front Feet
7
6
8
Water Inlet Hose
- RED fittings (Hot Water)
- BLUE fittings (Cold Water)
Mains Cable
9
Outlet Hose/Drain Hose (See
installation instructions sheet to
fit & position drain hose)
Back Feet (fixed)
10
Bleach Dispenser
Wash Bowl
11
12
Fabric Softener Dispenser
Agitator
13
Lint Filter
14
Frame Filter
11
12
10
9
11
14
13
12
