SimPure T1-400 - Installation Kit

Installation Kit
Carefully unpack your SimPure
®
T1-400 Water Filtration System. Layout the
parts, so you can familiarize yourself with the components, check nothing is
missing before you start the installation.
Package Contents List
Description
A
Main body
B
PP filter cartridge
C
CTO filter cartridge
D
RO filter cartridge
E
T33 filter cartridge
F
Tubing ¼” PE (White ,59 inches)
G
Tubing ¼” PE (Blue ,59 inches)
H
Tubing ¼” PE (Red ,59 inches)
I
Gooseneck faucet
J
Faucet adaptor ¼" tube QC
K
Drain saddle
L
Feedwater valve "
M
Spare parts kit
M1
⅜” male comp. x ½” female NPT convertor fitting
M2
½” male NPT x ⅜” female comp. convertor fitting
M3
Teflon tape (roll)
M4
Faucet mounting plate
M5
Self-tap screws M5X36mm & wall plugs (x5)
