Operation
20220752G 11
To change the damping level:
1. Press the button, hold for 2 seconds and release. The
display damping screen is shown [d1-d4].
2. Repeat the above. The figure flashes.
3. Select damping level (d1-d4) by pressing
or .
4. Press the
button and hold for 2 seconds to save the
setting.
5. Press the button shortly to enter the next sub screen
(alarm on/off) or press and hold for 2 seconds to return to
the main screen.
Wind Speed Alarm On/Off [A.On – A.OFF]
The IS15 Wind display has a true wind speed alarm, and it can be
turned on or off as desired.
1. Enter the display damping screen.
2. Apply a short press on the button. The wind speed
alarm On/Off screen is shown.
3. Press the button, hold for 2 seconds and release. The
figure flashes.
4. Select On or Off by pressing or .
5. Press the button and hold for 2 seconds to save the
setting.
6. Press the button shortly to enter the next sub screen
(alarm limit) or press the button and hold for 2 seconds
to return to the main screen.
Wind Speed Alarm Limit
The alarm limit can be set to any whole value in Knots, Metres
per second, Kilometres per hour or Beaufort. It is always valid,
and is controlled On or Off by the alarm On / Off setting.
The alarm limit is set as follows:
1. Enter the alarm on/off screen as described above.
2. Apply a short press on the button. The wind speed
alarm limit screen is shown.
3. Press the button, hold for 2 seconds and release. The
current value will be shown flashing.
4. Increase the alarm value using the button.
5. Decrease the alarm value using the button.
