6.2 Installation and Calibration Menu
The installation menu is arranged as follows:
Screen
Display
Screen 1 Screen 2 Screen 3 Screen 4
Analog
Digital
Apparent wind
angle
Illumination bank
bAn.1
Apparent wind
angle
Wind speed unit
SPd1
Apparent wind
angle
VMG to wind unit
SPd1
Apparent wind
angle
Wind angle,
automatic
calibration
OFS.A
Screen
Display
Screen 5 Screen 6 Screen 7 Screen 8
Analog
Digital
Apparent wind
angle
Wind angle offset
(manual calibration)
OFFS
Apparent wind
angle
Shop mode
(on/off)
SHOP
Apparent wind
angle
NMEA In/Out
n183
Apparent wind
angle
Roblink On/Off
robl
Screen
Display
Screen 9 Screen 10 Screen 11
Analog
Digital
Apparent wind
angle
Roblink test
tESt
Apparent wind
angle
Communication
reset C.rES
Apparent wind
angle
Master reset
rES
To enter the Installation Menu:
1. Press the
button, hold for 10 seconds and release to
access the Installation Mode.
2. Apply a short press on the or button to select one of
the LCD screens in the Installation Mode.
3. Press the button, hold for 2 seconds and release to
access a setting. The item to be set starts flashing.
4. Apply a short press on the or button to select a new
setting.
5. Press the button and hold for 2 seconds to save a
setting.
6. Apply a short press on the button to show the next
screen or press the button and hold for 2 seconds to
return to normal operation.
