Getting started |
RS90 Operating Manual
Handset parts
1
Red distress cover with button beneath
2
Screen
3
PT
T button
4
V
olume control
5
F
unc
tion keys
6
Keypad (wired handsets only).
Subscribing a wireless handset
At installation time, wir
eless handsets must be register
ed in the
transceiver
. F
or instructions, see
“Subscr
ibing a wireless handset”
on
page 74.
1
2
3
4
6
5
16
18
Table of Contents
