Installation and Maintenance
No. Description Qty No. Description Qty
1 Condenser Assy 1 20 Bolt 4
2 Capillary Sub-assy 1 21 Foam 4
3 Inhalation Tube Sub-assy 1 22 Sponge (sealing strip) 1
4 Compressor Gasket 1 23 Chassis Assy 1
5 Spring 4 24 Sponge 3
6 Compressor and Fittings 1 25 Motor base Assy 3
7 Compressor Gasket 1 26 Support (Electric box assy) 1
8 4-Way Valve Assy 1 27 Radiator 1
9 Water bae (4-way valve) 1 28 Electric Box Assy 1
10 Water bae (xing pipe) 1 29 Main Board 1
11 Centrifugal fan assy (inside) 1 30 Temperature Sensor 1
12 Centrifugal fan blade 1 31 Temperature Sensor 1
13 Brushless DC Motor 1 32 Electric Box Cover 1
14 Sensor Insert 2 33 Centrifugal fan assy(outside) 1
15 Evaporator Assy 1 34 Centrifugal fan blade 2
16 Foam (inner side) 1 35 Brushless DC Motor 1
17 Connecting Cable 1 36 Foam (outside) 1
18 Remote Controller 1 37 Cabinet 1
19 Mounting Plate Sub-Assy 2
Some models may not contain some parts,
please refer to the actual product.
