Sinclair Focus Plus YAC1FB9 User Manual

8
Service Manual
Parameter Unit Value
Model
ASH-18BIF2
Product Code CB419015600
Power
Supply
Rated Voltage V~ 220-240
Rated Frequency Hz 50
Phases 1
Power Supply Mode Outdoor
Cooling Capacity W 5200
Heating Capacity W 5300
Cooling Power Input W 1528
Heating Power Input W 1410
Cooling Current Input A 6.78
Heating Current Input A 6.26
Rated Input W 2600
Rated Current A 6.78
Air Flow Volume(SH/H/MH/M/ML/L/SL) m
3
/h 660/590/540/490/450/420/390
Dehumidifying Volume L/h 1.8
EER W/W 3.40
COP W/W 3.76
SEER W/W 7
SCOP(Average/Warmer/Colder) W/W /
Application Area m
2
23-34
Indoor
Unit
Indoor Unit Model
ASH-18BIF2
Fan Type Cross-ow
Fan Diameter Length(DXL) mm Ф106X706
Cooling Speed(SH/H/M/L/SL) r/min 1230/1150/1080/980/900/850800
Heating Speed(SH/H/M/L/SL) r/min 1350/1250/1150/1050/980/900/850
Fan Motor Power Output W 35
Fan Motor RLA A 0.35
Fan Motor Capacitor μF 2.5
Evaporator Form Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm Ф7
Evaporator Row-n Gap mm 2-1.4
Evaporator Coil Length (LXDXW) mm 715X25.4X304.8
Swing Motor Model MP35CJ/MP24HF
Swing Motor Power Output W 2.5/1.5
Fuse Current A 3.15
Sound Pressure Level(SH/H/MH/M/ML/L/SL) dB (A) 45/43/41/38/35/34/31
Sound Power Level(SH/H/MH/M/ML/L/SL) dB (A) 55/53/51/48/45/44/41
Dimension (WXHXD) mm 970X300X224
Dimension of Carton Box (LXWXH) mm 1038X380X305
Dimension of Package(LXWXH) mm 1041X383X320
Net Weight kg 13.5
Gross Weight kg 16.5
