Sinclair Focus Plus YAC1FB9 User Manual

7
Service Manual
Parameter Unit Value
Model
GWH12QC-K6DNA1D
GWH12QC-K6DNA5D
GWH12QC-K6DNE4D
GWH12QC-K6DNA1D
GWH12QC-K6DNA5D
GWH12QC-K6DNE4D
GWH12QC-K6DNB6D
GWH12QC-K6DNC2D
GWH12QC-K6DNB4D
GWH12QC-K6DNB2D
Product Code
CB419015501
CB425012301
CB470002901
CB419015500
CB425012300
CB470002900
CB435009400
CB439013100
CB434012600
CB432017800
Power
Supply
Rated Voltage V~ 220-240 220-240
Rated Frequency Hz 50 50
Phases 1 1
Power Supply Mode Outdoor Outdoor
Cooling Capacity W 3500 3500
Heating Capacity W 3670 3670
Cooling Power Input W 1085 1085
Heating Power Input W 990 990
Cooling Current Input A 5.0 5.0
Heating Current Input A 4.5 4.5
Rated Input W 1500 1500
Rated Current A 5.0 5.0
Air Flow Volume(SS/H/MH/M/ML/L/SL) m
3
/h 680/620/560/490/450/420/390 680/620/560/490/450/420/390
Dehumidifying Volume L/h 1.4 1.4
EER W/W 3.23 3.23
COP W/W 3.71 3.71
SEER W/W 7 7
SCOP(Average/Warmer/Colder) W/W 4/5.1/3.3 4/5.1/3.3
Application Area m
2
16-24 16-24
Indoor
Unit
Fan Type Cross-ow Cross-ow
Fan Diameter Length(DXL) mm Ф98X633.5 Ф98X633.5
Cooling Speed(SS/H/MH/M/ML/L/SL) r/min 1350/1200/1100/1000/920/850/800 1350/1200/1100/1000/920/850/800
Heating Speed(SS/H/MH/M/ML/L/SL) r/min 1300/1200/1120/1050/980/900/850 1300/1200/1120/1050/980/900/850
Fan Motor Power Output W 20 20
Fan Motor RLA A 0.31 0.31
Fan Motor Capacitor μF 1.5 1.5
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm Ф5 Ф5
Evaporator Row-n Gap mm 2-1.5 2-1.5
Evaporator Coil Length (LXDXW) mm 635X22.8X306.3 635X22.8X306.3
Swing Motor Model MP24BA/MP24EB MP24BA/MP24EB
Swing Motor Power Output W 1.5/1.5 1.5/1.5
Fuse Current A 3.15 3.15
Sound Pressure Level(SS/H/MH/M/
ML/L/SL)
dB (A) 42/38/35/32/30/28/26 42/38/35/32/30/28/26
Sound Power Level(SS/H/MH/M/ML/
L/SL)
dB (A) 57/50/47/44/42/40/38 57/50/47/44/42/40/38
Dimension (WXHXD) mm 918X289X209 918X289X209
Dimension of Carton Box (LXWXH) mm 918X278/364 918X278/364
Dimension of Package(LXWXH) mm 931X281X379 931X281X379
Net Weight kg 10.5 10.5
Gross Weight kg 12.5 12.5
Outdoor
Unit
Outdoor Unit Model ASH-13BIF2
Outdoor Unit Product Code CB419W15501
Compressor Manufacturer
ZHUHAI LANDA
COMPRESSOR CO.,LTD
Compressor Model QXF-A102zE190B
Compressor Oil FW68DA
Compressor Type Rotary
Compressor LRA. A /
Compressor RLA A 4.6
Compressor Power Input W 1023
Compressor Overload Protector HPC115/95U1/KSD115
℃
Throttling Method Electron expansion valve
Set Temperature Range ºC 16~30
Cooling Operation Ambient Temperature
Range
ºC
-15~43
Heating Operation Ambient Temperature
Range
ºC
-22~24
Condenser Form Aluminum Fin-copper Tube
Condenser Pipe Diameter mm Φ7.94
Condenser Rows-n Gap mm 1-1.4
Condenser Coil Length (LXDXW) mm 731X19.05X550
Fan Motor Speed rpm 900
Fan Motor Power Output W 30
Fan Motor RLA A 0.36
Fan Motor Capacitor μF /
Outdoor Unit Air Flow Volume m
3
/h 2200
Fan Type Axial-ow
Fan Diameter mm Ф438
Defrosting Method Automatic Defrosting
Climate Type T1
Isolation I
Moisture Protection IPX4
Permissible Excessive Operating Pressure
for the Discharge Side
MPa 4.3
Permissible Excessive Operating Pressure
for the Suction Side
MPa 2.5
Sound Pressure Level (H/M/L) dB (A) 52/-/-
Sound Power Level (H/M/L) dB (A) 62/-/-
Dimension(WXHXD) mm 848X596X320
Dimension of Carton Box (LXWXH) mm 878X360X630
Dimension of Package(LXWXH) mm 881X363X645
Net Weight kg 31
Gross Weight kg 34
Refrigerant R32
Refrigerant Charge kg 0.7
Connection
Pipe
Connection Pipe Length m 5
Connection Pipe Gas Additional Charge g/m 16
Outer Diameter Liquid Pipe mm Ф6
Outer Diameter Gas Pipe mm Ф9.52
Max Distance Height m 10
Max Distance Length m 20
Note: The connection pipe applies metric diameter.
The above data is subject to change without notice. Please refer to the nameplate of the unit.
