Sinclair Focus Plus YAC1FB9 User Manual

10
Service Manual
Parameter Unit Value
Model
ASH-24BIF2
Product Code
CB470N02800
Power
Supply
Rated Voltage V~ 220-240
Rated Frequency Hz 50
Phases 1
Power Supply Mode Outdoor
Cooling Capacity W 7000
Heating Capacity W 7400
Cooling Power Input W 1900
Heating Power Input W 1897
Cooling Current Input A 8.73
Heating Current Input A 8.84
Rated Input W 3750
Rated Current A 8.73
Air Flow Volume(SH/H/MH/M/ML/L/SL) m
3
/h 660/590/540/490/450/420/390
Dehumidifying Volume L/h 2.4
EER W/W 3.68
COP W/W 3.90
SEER W/W 6.5
SCOP(Average/Warmer/Colder) W/W /
Application Area m
2
27-42
Indoor
Unit
Fan Type Cross-ow
Fan Diameter Length(DXL) mm Φ108X830
Cooling Speed(SH/H/M/L/SL) r/min 1250/1150/1050/950/900/850/800
Heating Speed(SH/H/M/L/SL) r/min 1250/1150/1050/1000/950/900/850
Fan Motor Power Output W 35
Fan Motor RLA A 0.35
Fan Motor Capacitor μF /
Evaporator Form Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm Ф7
Evaporator Row-n Gap mm 2-1.4
Evaporator Coil Length (LXDXW) mm 850X25.4X342.9
Swing Motor Model MP35CJ/MP24HF
Swing Motor Power Output W 2.5/1.5
Fuse Current A 3.15
Sound Pressure Level(SH/H/MH/M/ML/L/SL) dB (A) 48/45/42/39/37/36/33
Sound Power Level(SH/H/MH/M/ML/L/SL) dB (A) 58/55/52/49/47/46/43
Dimension (WXHXD) mm 1078X325X246
Dimension of Carton Box (LXWXH) mm 1145X410X335
Dimension of Package(LXWXH) mm 1148X413X350
Net Weight kg 16.5
Gross Weight kg 20

Sinclair Focus Plus YAC1FB9 Specifications

General

Brand	Sinclair
Model	Focus Plus YAC1FB9
Category	Air Conditioner
Language	English
