Sinclair Focus Plus YAC1FB9 User Manual

11
Service Manual
Outdoor
Unit
Outdoor Unit Model ASH-24BIF2
Outdoor Unit Product Code CB419W15700
Compressor Manufacturer
ZHUHAI LANDA COMPRESSOR
CO., LTD
Compressor Model QXFS-D25zX090H
Compressor Oil FW68DA
Compressor Type Rotary
Compressor LRA. A 24
Compressor RLA A 11.7
Compressor Power Input W 2420
Compressor Overload Protector HPC115/95U1/KSD115
℃
Throttling Method Electron expansion valve
Set Temperature Range ºC 16~30
Cooling Operation Ambient Temperature
Range
ºC -15~43
Heating Operation Ambient Temperature
Range
ºC -22~24
Condenser Form Aluminum Fin-copper Tube
Condenser Pipe Diameter mm Φ7
Condenser Rows-n Gap mm 2-1.4
mmCondenser Coil Length (LXDXW) 935X38.1X660
Fan Motor Speed rpm 800
Fan Motor Power Output W 60
Fan Motor RLA A 0.58
Fan Motor Capacitor μF /
Outdoor Unit Air Flow Volume m
3
/h 3200
Fan Type Axial-ow
Fan Diameter mm Ф520
Defrosting Method Automatic Defrosting
Climate Type T1
Isolation I
Moisture Protection IPX4
Permissible Excessive Operating Pressure
for the Discharge Side
MPa 4.3
Permissible Excessive Operating Pressure
for the Suction Side
MPa 2.5
Sound Pressure Level (H/M/L) dB (A) 57/-/-
Sound Power Level (H/M/L) dB (A) 67/-/-
Dimension(WXHXD) mm 963X700X396
mmDimension of Carton Box (LXWXH) 1026X455X735
Dimension of Package(LXWXH) mm 1029X458X750
Net Weight kg 53.5
Gross Weight kg 58
Refrigerant R32
Refrigerant Charge kg 1.7
Connection
Pipe
Connection Pipe Length m 5
g/mConnection Pipe Gas Additional Charge 50
Outer Diameter Liquid Pipe mm Ф6
Outer Diameter Gas Pipe mm Ф16
Max Distance Height m 10
Max Distance Length m
25
Note: The connection pipe applies metric diameter.
The above data is subject to change without notice. Please refer to the nameplate of the unit.
