Appendix 4: List of Resistance for T
emperature Sensor
Resistance T
able of Ambient Temperature Sensor for Indoor and Outdoor Units(15K)
T
emp(
o
C) Resistance(kΩ) T
emp(
o
C) Resistance(kΩ) T
emp(
o
C) Resistance(kΩ) T
emp(
o
C) Resistance(kΩ)
-19 138.10 0 49.02 20 18.75 40 7.97
-18 128.60 2 44.31 22 17.14 42 7.35
-16 1
15.00 4 40.09 24 15.68 44 6.79
-14 102.90 6 36.32 26 14.36 46 6.28
-12 92.22 8 32.94 28 13.16 48 5.81
-10 82.75 10 29.90 30 12.07 50 5.38
-8 74.35 12 27.18 32 11.09 52 4.99
-6 66.88 14 24.73 34 10.20 54 4.63
-4 60.23 16 22.53 36 9.38 56 4.29
-2 54.31 18 20.54 38 8.64 58 3.99
Resistance T
able of Tube Temperature Sensors for Indoor and Outdoor (20K)
Resistance Table of Discharge Temperature Sensor for Outdoor(50K)
T
emp(
o
C) Resistance(kΩ) T
emp(
o
C) Resistance(kΩ) T
emp(
o
C) Resistance(kΩ) T
emp(
o
C) Resistance(kΩ)
-19 181.40 20 25.01 60 4.95 100 1.35
-15 145.00 25 20.00 65 4.14 105 1.16
-10 1
10.30 30 16.10 70 3.48 110 1.01
-5 84.61 35 13.04 75 2.94 115 0.88
0 65.37 40 10.62 80 2.50 120 0.77
5 50.87 45 8.71 85 2.13 125 0.67
10 39.87 50 7.17 90 1.82 130 0.59
15 31.47 55 5.94 95 1.56 135 0.52
T
emp(
o
C) Resistance(kΩ) T
emp(
o
C) Resistance(kΩ) T
emp(
o
C) Resistance(kΩ) T
emp(
o
C) Resistance(kΩ)
-30 91
1.400 10 98 50 17.65 90 4.469
-25 660.8 15 77.35 55 14.62 95 3.841
-20 486.5 20 61.48 60 12.17 100 3.315
-15 362.9 25 49.19 65 10.18 105 2.872
-10 274 30 39.61 70 8.555 110 2.498
-5 209 35 32.09 75 7.224 115 2.182
0 161 40 26.15 80 6.129 120 1.912
5 125.1 45 21.43 85 5.222 125 1.682
