Sinclair RAY SIH-09BIR - 2 Specifications; Specification Sheet

2
Technical Information
Service Manual
2.1 Specication Sheet
2. Specications
Model
SIH+SOH-09BIR2
Power
Supply
Rated Voltage
V~
220-240
Rated Frequency
Hz
50
Phases
1
Power Supply Mode
Outdoor
Cooling Capacity
W
2700
Heating Capacity
W
2800
Cooling Power Input
W
725
Heating Power Input
W
685
Cooling Current Input
A
3.45
Heating Current Input
A
3.19
Rated Input
W
1500
Rated Cooling Current
A
6
Rated Heating Current
A
7.5
Air Flow Volume
m
3
/h
550/520/480/400/340/310/280
Dehumidifying Volume
L/h 0.8
EER
W/W
3.72
COP W/W 4.09
SEER 6.8
HSPF /
Application Area
m
2
10-16
Indoor Unit
Model
SIH-09BIR
Fan Type
Cross-ow
Fan Diameter Length(DXL)
mm
Ф93X580
Cooling Speed
r/min
1300/1200/1120/1050/920/800/750
Heating Speed
r/min
1300/1200/1120/1050/950/850/800
Fan Motor Power Output
W
20
Fan Motor RLA
A
0.22
Fan Motor Capacitor μF
1
Evaporator Form Aluminum Fin-copper Tube
Evaporator Pipe Diameter
mm
Ф5
Evaporator Row-n Gap
mm 2-1.4
Evaporator Coil Length (LXDXW)
mm
584X22.8X266.7
Swing Motor Model
MP24AN
Swing Motor Power Output
W
1.5
Fuse Current
A
3.15
Sound Pressure Level
dB (A)
Cooling: 40/37/35/33/29/26/21
Heating: 40/37/35/33/30/26/24
Sound Power Level
dB (A)
Cooling: 56/49/47/45/41/37/34
Heating: 55/49/47/45/42/38/35
Dimension (WXHXD)
mm
773X250X185
Dimension of Carton Box (LXWXH)
mm
817X306X244
Dimension of Package (LXWXH)
mm
822X322X255
Net Weight kg
8.5
Gross Weight kg
9.5
