3
Technical Information
Service Manual
Outdoor
Unit
Outdoor Unit Model
SOH-09BIR2
Compressor Manufacturer
ZHUHAI LANDA COMPRESSOR
CO.,LTD
Compressor Model
QXF-A082zC170
Compressor Oil ZE-G;ES RB68GX or equivalent
Compressor Type
Rotary
Compressor LRA.
A
15
Compressor RLA
A
2.56
Compressor Power Input
W
757
Compressor Overload Protector
/
Throttling Method Capillary
Set Temperature Range
ºC
16~30
Cooling Operation Ambient Temperature Range
ºC
-15~43
Heating Operation Ambient Temperature Range
ºC -15~24
Condenser Form
Aluminum Fin-copper Tube
Condenser Pipe Diameter
mm Ф7
Condenser Rows-n Gap
mm
1-1.2
Condenser Coil Length (LXDXW)
mm
666X19.05X527
Fan Motor Speed rpm
850
Fan Motor Power Output
W
30
Fan Motor RLA
A
0.4
Fan Motor Capacitor μF
/
Outdoor Unit Air Flow Volume
m
3
/h 1950
Fan Type
Axial-ow
Fan Diameter
mm
Ф400
Defrosting Method Automatic Defrosting
Climate Type
T1
Isolation
I
Moisture Protection
IPX4
Permissible Excessive Operating Pressure for
the Discharge Side
MPa
4.3
Permissible Excessive Operating Pressure for
the Suction Side
MPa 2.5
Sound Pressure Level
dB (A)
51
Sound Power Level
dB (A)
60
Dimension(WXHXD)
mm
732X555X330
Dimension of Carton Box (LXWXH)
mm
791X373X590
Dimension of Package(LXWXH)
mm
794X376X615
Net Weight kg
24.5
Gross Weight kg
27
Refrigerant
R32
Refrigerant Charge kg
0.5
Connection
Pipe
Connection Pipe Length
m
5
Connection Pipe Gas Additional Charge g/m
16
Outer Diameter Liquid Pipe
inch 1/4
Outer Diameter Gas Pipe
inch
3/8
Max Distance Height
m
10
Max Distance Length
m
15
Note: The connection pipe applies metric diameter.
