Outdoor Unit Model SOH-12BIR2
Compressor Manufacturer
ZHUHAI LANDA COMPRESSOR
CO,LTD.
Compressor Model
QXF-N088zC170
Compressor Oil
FW68DA or equivalent
Compressor Type
Rotary
Compressor LRA. A
/
Compressor RLA A
3.6
Compressor Power Input W
758
Compressor Overload Protector
/
Throttling Method
Capillary
Set Temperature Range ºC
16~30
Cooling Operation Ambient Temperature Range ºC
-15~43
Heating Operation Ambient Temperature Range ºC
-15~24
Condenser Form
Aluminum Fin-copper Tube
Condenser Pipe Diameter mm
Ф7
Condenser Rows-n Gap mm
1-1.4
Condenser Coil Length (LXDXW) mm
700X19.05X528
Fan Motor Speed rpm
900
Fan Motor Power Output W
28
Fan Motor RLA A
0.4
Fan Motor Capacitor μF
2.5
Outdoor Unit Air Flow Volume m
3
/h
1950
Fan Type
Axial-ow
Fan Diameter mm
Ф400
Defrosting Method
Automatic Defrosting
Climate Type
T1
Isolation
I
Moisture Protection
IPX4
Permissible Excessive Operating Pressure for
the Discharge Side
MPa
4.3
Permissible Excessive Operating Pressure for
the Suction Side
MPa
2.5
Sound Pressure Level dB (A)
52
Sound Power Level dB (A)
63
Dimension(WXHXD) mm
732X555X330
Dimension of Carton Box (LXWXH) mm
791X373X590
Dimension of Package(LXWXH) mm
794X376X615
Net Weight kg
25
Gross Weight kg
27.5
Refrigerant
R32
Refrigerant Charge kg
0.55
Connection
Pipe
Connection Pipe Length m
5
Connection Pipe Gas Additional Charge g/m
20
Outer Diameter Liquid Pipe inch
1/4
Outer Diameter Gas Pipe inch
3/8
Max Distance Height m
10
Max Distance Length m
20
Note: The connection pipe applies metric diameter.
