Sinee A90 Series User Manual

User Manual of A90 Series Inverter
189
F08.12
Multi-segment
speed 13
0.00 to maximum frequency
F00.16
Hz
50.00
●
F08.13
Multi-segment
speed 14
0.00 to maximum frequency
F00.16
Hz
50.00
●
F08.14
Multi-segment
speed 15
0.00 to maximum frequency
F00.16
Hz
50.00
●
The 16-segment speed can be provided according to the multi-segment speed control
terminal, 15-segment frequency command and digital frequency setting F00.07.
Table 7-10 Combination of Multi-segment Speed Command and Multi-segment Speed
Terminal
Segment
Speed
Multi-seg
ment speed
terminal 4
Multi-seg
ment
speed
terminal 3
Multi-seg
ment
speed
terminal 2
Multi-segm
ent speed
terminal 1
Selected
frequency
Corresponding
function code
1
Invalid
Invalid
Invalid
Invalid
Digital
frequency
setting
Depending on
F00.07
2
Invalid
Invalid
Invalid
Valid
Multi-segment
speed 1
F08.00
3
Invalid
Invalid
Valid
Invalid
Multi-segment
speed 2
F08.01
4
Invalid
Invalid
Valid
Valid
Multi-segment
speed 3
F08.02
5
Invalid
Valid
Invalid
Invalid
Multi-segment
speed 4
F08.03
6
Invalid
Valid
Invalid
Valid
Multi-segment
speed 5
F08.04
7
Invalid
Valid
Valid
Invalid
Multi-segment
speed 6
F08.05
8
Invalid
Valid
Valid
Valid
Multi-segment
speed 7
F08.06
9
Valid
Invalid
Invalid
Invalid
Multi-segment
speed 8
F08.07
10
Valid
Invalid
Invalid
Valid
Multi-segment
speed 9
F08.08
11
Valid
Invalid
Valid
Invalid
Multi- speed
10
F08.09
12
Valid
Invalid
Valid
Valid
Multi-segment
speed 11
F08.10
13
Valid
Valid
Invalid
Invalid
Multi-segment
speed 12
F08.11
